| Hardware Specification |
| ◆Solution |
:MTK8550 |
| ◆Laser |
:SANYO414 |
| Panel Specifications |
| ◆ Panel |
:10 inch HD Digital Panel |
| ◆ Screen Ratio |
:16:9 |
| ◆ Resolution |
:1024*600 |
| ◆ Contract Ratio |
:500:1 |
| Power Supply Specifications |
| ◆ Power Supply(Adapter) |
:DC 12V |
| ◆ LI Battery |
:Built -in 7.4V(The Battery can play about 3 hours) |
| ◆ Power Indicator (LED) |
:Power ON :Green ; Charging :Red ; |
| ◆ Charge Management |
:Yes |
| Main Features |
| ◆ Playback disc formats |
:BD，BD-R，BD-RE，DVD-R/RW，DVD+R/RW，DVD-Video，VCD，CD，CD-R/RW |
| ◆ Video formats |
:H.264/VC1/MPEG1/MPEG-2/MPEG4 |
| ◆ Audio formats |
:Dolby Digital , Dolby Digital Plus, Dolby TrueHD, DTS-HD
|
| ◆ USB HOST |
:High speed USB 2.0 support U DISK and USB HDD |
| ◆ Hihg Difinition video output |
:SD/HD max.1920x1080 pixel |
| ◆ LAN |
:Ethernet ,10/100Mbps,BD-LIVE ,BD-J |
| ◆ HDMI |
:Support V1.3 HDMI/HDCP |
| ◆ Card reader |
:SD/MMC /MS |
| ◆ AV OUTPUT/INPUT |
:Yes |
| ◆ Anti-shock |
:Yes |
| ◆Support panel rotating |
:Yes |
| ◆ TV |
:Optional(ISDB-T :Only FULL SEG ready) |
| JACKS |
| ◆ HDMI Socket |
:1PCS |
| ◆ LAN Socket |
:1PCS |
| ◆ USB Socket |
:1 pcs |
| ◆SD/MMC /MS Card Jack |
:1 pcs |
| ◆ 4.0 mm DC-IN Jack |
:1 pcs |
| ◆3.5 mm stereo earphone jack |
:1 pcs |
| ◆3.5 mm AV jack |
:2 pcs (AV OUT and AV IN) |
| ◆ Buttons |
Hard Keys |
| Accessories |
| ◆AV Cable |
:1 pcs (2CH Audio, 1CH CVBS) |
| ◆ Remote control |
:1 pcs |
| ◆User Manual |
:1 pcs |
| ◆Power Adapter |
:1 pcs |
| ◆ Warranty cards |
:1 pcs |
| ◆ Headphone Cable |
:1 pcs |
| ◆ Antenna |
:Optional |
| ◆ Car Adapter |
:1 pcs |
